UBiQUiTi Switch 12x1000Mbps + 4x2500Mbps + 2x10Gbps SFP+, Menedzselhető, Asztali, Falra rögzíthető - USW-PRO-MAX-16

• Részletek
• Adatok

Részletek

Technical Specifications

Mechanical
Dimensions	325.1 x 160 x 43.7 mm (12.8 x 6.3 x 1.7")
Weight	1.95 kg (4.3 lb)
Enclosure material	SGCC steel
Hardware
Management interface	Ethernet In-Band
Networking interface	(12) GbE RJ45 ports (4) 1/2.5 GbE RJ45 ports (2) 10G SFP+ ports
Total non-blocking throughput	42 Gbps
Switching capacity	84 Gbps
Forwarding rate	62.496 Mpps
Power method	Type-C adapter
Power supply	5V, 25W
Max. power consumption	25W
LCM display	(1) 1.3" touchscreen
Button	Factory reset
Ambient operating temperature	-5 to 40° C (23 to 104° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Switching Features
Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	DHCP for locally-managed networks DHCP relay Inter-VLAN routing between networks on same switch Static routing between local networks Network isolation with ACLs
Etherlighting™
Ethernet	Locating Speed/link Native VLAN/network
SFP+	Locating Speed/link Native VLAN/network

Adatok

Gyártó:

UBIQUITI

EAN:

810084694565

Listaár:

134 493 HUF

Gyártó:

UBIQUITI

Gyártói cikkszám:

USW-PRO-MAX-16

Garancia:

24 hónap

Rack-be szerelhető:

Nincs

Menedzselhetőség:

Web

Portok száma:

16

Switching kapacitás:

84

Menedzselhető:

Van

PoE (Power over Ethernet):

Nincs

Áteresztő képesség:

42

SFP port:

2

Tömeg:

2,98 kg/db
